Beyma 12MC500
R2,778.00The Beyma 12MC500 is a 12″ mid-bass driver designed for professional audio systems that require high power handling and efficiency. Its robust construction and advanced Maltcross cooling technology make it ideal for 2- or 3-way PA systems and line arrays.
features
- Maltcross cooling system reduces power compression
- Aluminum demodulating ring minimizes distortion
- ±8 mm Xmax allows for extended linear excursion
- Weatherproof cone treatment on both sides for increased durability
- 40 mm peak-to-peak excursion before damage ensures mechanical reliability
- Optimized for 2- or 3-way PA systems and line arrays
- 2.5″ copper wire voice coil enhances thermal stability
Celto Acoustique 12PF600-8
R2,766.00The CELTO 12PF600-8 forms part of the new range of loose mid-bass drivers stocked by BC Electronics. As usual with CELTO products, there has been absolutely no compromise in design, selection of materials used, manufacturing and quality control. This 12” driver features a beautifully finished powder coated die cast aluminium basket, 240°C PI wire voice coil, premium Canadian pulp paper cone with waterproof coating on both sides, high purity and temperature DMEGC Y30 magnate, and secure square push terminals able to accommodate 5mm diameter connecting wire.
FEATURES
Balanced tonality ideal for 2-way speakers
High efficiency
Water resistant KEVLAR® loaded paper cone
Optimized parameters for compact cabinets
SPECIFICATIONS
Nominal diameter = 320mm (12 inch)
Nominal Impedance = 8Ω
Power handling = 500W RMS (AES Standard)
Sensitivity = 97dB / 1W / 1m
Voice coil diameter = 75mm
Voice coil height Hvc = 24mm
Voice coil air gap Hag = 10mm
Xmax (Hvc-Hag)/2 + Hag/4 = ±9.5mm
Xmech (peak-peak) = 42mm
Voice coil winding = 2 layers IN / OUT
Voice coil material = 240°C Thermal Class CCAW
Voice coil former = T600 fiberglass
Suspension = Triple roll, impregnated fabric
Spider = single, cold formed NOMEX®
Cone = fiber loaded treated paper
Chassis = Die Cast Aluminum
Magnet = Ø180mm Y30 Ferrite
MOUNTING & SHIPPING
Overall diameter = 315mm
Bolt circle diameter = 302mm (8*M5)
Baffle cutout diameter = 282mm
Flange and gasket thickness = 10mm
Overall depth = 143mm
Net weight = 7kg
Shipping weight = 8kg
Shipping box = 340x340x195mm
T&S PARAMETERS
F(s) = 51Hz
Q(ms) = 7.472
V(as) = 66ℓ
M(ms) = 64g
R(ms) = 2.74kg/s
S(d) = 552cm²
V(d) = 0.524ℓ
R(e) = 5.28Ω
Q(es) = 0.452
C(ms) = 0.152mm/N
Q(ts) = 0.424
L(e) 1kHz = 1.08mH
BL = 15.5
n(0) = 1.9%
Wharfedale Loose Woofer For Titan12 Passive
R1,336.00Loose Woofer For Titan12 Passive
Beyma 12P80FE V2
R4,552.00KEY FEATURES
● 700 WAES power handling capacity
● High sensitivity: 99 dB (1W / 1m)
● Wide usable frequency range
● Low harmonic distortion
● Low resonant frequency: 48 Hz
● Low power compression losses
● Weatherproof cone with treatment for both sides
● 4” DUO double layer in/out aluminium voice coil
● Conex spider
● Extended controlled displacement: Xmax ± 7,5 mm
● 52 mm peak-to-peak excursion before damage
Wharfedale Kinetic woofer 12/ PSX112 4OHM
R848.00Speaker – replacement woofer for Kinetic1 and PSX112
4ohm
Celto Acoustique 12CMB500
R5,669.0012″ Mid bass loose speaker
500W RMS
8ohm
3” In/Out CCAW Voice coil
Aluminium basket
Celto Acoustique 12NG500-8
R2,004.00The CELTO 12NG500-8 forms part of the new range of loose mid-bass drivers stocked by BC Electronics. As usual with CELTO products, there has been absolutely no compromise in design, selection of materials used, manufacturing and quality control. This 12” driver features a beautifully finished powder coated die cast aluminium basket, Japanese wire 240°C voice coil, KEVLAR® loaded Canadian pulp paper cone with waterproof coating on both sides, high purity and temperature DMEGC Y35 magnate, and secure square push terminals able to accommodate 5mm diameter connecting wire.
FEATURES
Balanced tonality ideal for 2-way speakers
High efficiency
Water resistant paper cone
Optimized parameters for compact cabinets
SPECIFICATIONS
Nominal diameter = 320mm (12 inch)
Nominal Impedance = 8Ω
Power handling = 500W RMS (AES Standard)
Sensitivity = 97dB / 1W / 1m
Voice coil diameter = 75mm
Voice coil height Hvc = 20.5mm
Voice coil air gap Hag = 9mm
Xmax (Hvc-Hag)/2 + Hag/4 = ±8mm
Xmech (peak-peak) = 40mm
Voice coil winding = 2 layers IN / OUT
Voice coil material = 240°C Thermal Class CCAW
Voice coil former = T600 fiberglass
Suspension = Triple roll, impregnated fabric
Spider = single, cold formed NOMEX®
Cone = fiber loaded treated paper
Chassis = Die Cast Aluminum
Magnet = Ø180mm Y30 Ferrite
MOUNTING & SHIPPING
Overall diameter = 315mm
Bolt circle diameter = 302mm (8*M5)
Baffle cutout diameter = 282mm
Flange and gasket thickness = 10mm
Overall depth = 139mm
Net weight = 6kg
Shipping weight = 7kg
Shipping box = 350x310x180mm
T&S PARAMETERS
F(s) = 49Hz
Q(ms) = 8.254
V(as) = 75ℓ
M(ms) = 61g
R(ms) = 2.27kg/s
S(d) = 551cm²
V(d) = 0.441ℓ
R(e) = 5.4Ω
Q(es) = 0.453
C(ms) = 0.173mm/N
Q(ts) = 0.43
L(e) 1kHz = 1.08mH
BL = 15
n(0) = 1.87%
Electro-Voice ETX-12P powered speaker
R41,599.00Electro Voice Etx-12P Powered Speaker 12-Inch Lf Smx Woofer
1.25-Inch Hf Titanium Compression Driver
2000 W Class-D Power Amplifier With Integrated Fir-Drive Dsp
135 Db Peak Spl
Beyma 12WRS400
R2,764.00Speaker – Loose Driver, 12″ 400W
12Wrs400 8Ohm Nominal Impedance
8 Ohm
Power Capacity
400 W Aes
Nominal Diameter
300 Mm 12 In
Sensitivity
97 Db 1 W @ 1 M @ Zn
Minimum Impedance
7 Ohm
Frequency Range
45-5000 Hz
Program Power
800 W
Recommended Enclosure Volume
30 / 100 L 1.06 / 3.53 Ft.³
Voice Coil Diameter
76.2 Mm 3 In
Bl Factor
17.4 N/A
Moving Mass
0.063 Kg
Winding Length
16 Mm
Air Gap Height
8 Mm
Xdamage Pp
30 Mm
Hybrid 12H600
R1,403.0012″ loose speaker
Frame: Die-cast Aluminum basket
Power Handling: 600W RMS
Impedance: 8Ohm
Voice Coil: 4″
Magnet: Ferrite, 100Oz
Efficiency: 1.48%
SPL 1W/1m: 94dB
Fs: 67Hz
Service recone-kit available for this model
HYBRID is a South African brand with over 30 years’ experience in professional audio, stage and lighting. Our brand is aimed specifically at the African market to meet our continent’s demands for features, performance and budget.
HYBRID+ is our flagship brand, offering features and performance comparable to world renowned brands and making HYBRID+ one of the best price-to-performance ratio brands.
Hybrid 12H150S
R570.0012″ loose speaker
Frame: Pressed metal basket
Power Handling: 150W RMS
Impedance: 8Ohm
Voice Coil: 2″
Magnet: Ferrite, 40Oz
Efficiency: 0.9%
SPL 1W/1m: 92dB
Fs: 48Hz
Replacement woofer for models;
Hybrid PM12
HYBRID is a South African brand with over 30 years’ experience in professional audio, stage and lighting. Our brand is aimed specifically at the African market to meet our continent’s demands for features, performance and budget.
HYBRID+ is our flagship brand, offering features and performance comparable to world renowned brands and making HYBRID+ one of the best price-to-performance ratio brands.
Hybrid 12H200S
R648.0012″ loose speaker
Frame: Pressed metal basket
Power Handling: 150W RMS
Impedance: 8Ohm
Voice Coil: 2.5″
Magnet: Ferrite, 50Oz
Efficiency: 0.84%
SPL 1W/1m: 91dB
Fs: 61Hz
Replacement woofer for models;
Hybrid PB12N
Hybrid PLB12
HYBRID is a South African brand with over 30 years’ experience in professional audio, stage and lighting. Our brand is aimed specifically at the African market to meet our continent’s demands for features, performance and budget.
HYBRID+ is our flagship brand, offering features and performance comparable to world renowned brands and making HYBRID+ one of the best price-to-performance ratio brands.
Hybrid 12H200C
R804.0012″ loose speaker
Frame: Die-cast Aluminum basket
Power Handling: 200W RMS
Impedance: 8Ohm
Voice Coil: 2.5″
Magnet: Ferrite, 50Oz
Efficiency: 0.8%
SPL 1W/1m: 91dB
Fs: 61Hz
HYBRID is a South African brand with over 30 years’ experience in professional audio, stage and lighting. Our brand is aimed specifically at the African market to meet our continent’s demands for features, performance and budget.
HYBRID+ is our flagship brand, offering features and performance comparable to world renowned brands and making HYBRID+ one of the best price-to-performance ratio brands.
