BEYMA 18LEX1200FE
R4,512.00High power handling and low distortion 18” subwoofer
● Exclusive Malt Cross® Technology Cooling System
● Low power compression losses
● High sensitivity: 97 dB (1W / 1m)
● FEA optimized ceraminc magnetic circuit
● Ultra low air noise
● Optimized linear behaviour
Weatherproof cone with treatment for both sides
● Double silicone spider
● 4” DUO double layer in/out copper voice coil
● Aluminium demodulating ring
● Extended controlled displacement: Xmax ± 11 mm
● 48 mm peak-to-peak excursion before damage
● Optimized for direct radiation and band-pass subwoofer
applications
Celto Acoustique 18NGW1200
R3,552.00As a world leading manufacturer, CELTO meticulously engineered this premium woofer to offer top class performance, consistency and long-term reliability. Featuring an exclusive blend of Canadian pulp cone reinforced by KEVLAR fibre, this high-efficiency driver has been designed to provide deep and precise low frequency reproduction in compact vented cabinets.
The 18NGW1200 features the beautifully crafted CELTO low turbulence aluminium basket with a flawless powder-coated finish, robust push terminal connectors, and 240°C thermal class voice coil (500°C peak), guaranteeing the longevity of this product.
With extensive experience serving the African market since 2010, CELTO designed the new NGW series specifically to withstand the high physical and electrical demands of our continent, including but not limited to an anti-shift motor system assembly and a dual-layer glue rivet process to avoid broken spiders.
FEATURES
Long excursion, Low distortion design
Deep, clean and punchy sound
Water resistant KEVLAR® loaded paper cone
Optimized parameters for compact cabinets
SPECIFICATIONS
Nominal diameter = 460mm (18 inch)
Nominal Impedance = 8 ohms
Power handling = 1200W RMS (AES Standard)
Sensitivity = 97 dB / 1W / 1m
Voice coil diameter = 4 inch (100mm)
Voice coil height Hvc = 26mm
Voice coil air gap Hag = 12mm
Xmax (Hvc-Hag)/2 + Hag/4 = ±10mm
Xmech (peak-peak) = 50mm
Voice coil winding = 2 layers IN / OUT
Voice coil material = 240°C Thermal Class Copper
Voice coil former = BAF fiberglass
Suspension = Triple roll, impregnated fabric
Spider = dual with silicon damping, NOMEX®
Cone = fibre loaded, waterproof treated paper
Chassis = Die Cast Aluminium
Magnet = Ø220mm Y35 Ferrite
MOUNTING & SHIPPING
Overall diameter = 470 mm
Bolt circle diameter = 445 mm
Baffle cutout diameter = 422 mm
Flange and gasket thickness = 13 mm
Overall depth = 212 mm
Net weight = 13 kg
Shipping weight = 15 kg
Shipping box = 500x455x265 mm
T&S PARAMETERS
F(s) = 35 Hz
Q(ms) = 10.325
V(as) = 206 litres
M(ms) = 218 grams
R(ms) = 4.568 kg/s
S(d) = 1225 sq.cm
V(d) = 1.225 liters
R(e) = 5.7 ohms
Q(es) = 0.431
C(ms) = 0.0962 mm/N
Q(ts) = 0.416
L(e) 1kHz = 1.98 mH
BL = 24.9
n(0) = 2.01%
Celto Acoustique 18SW1500-8 loose driver
R4,794.00The SW series of subwoofers are the flagship of the CELTO range of loose bass transducers. There has been absolutely no compromise in design, selection of the materials used, manufacturing and the QC process.
The 18SW1500 is a beautifully finished ultra-thick powder coated aluminum die-cast woofer, with a solid <0.1% carbon CNC machined steel T-Yoke, French bobbin with Japanese wire 240°C voice coil, Japanese / USA damper, water resistant fiber loaded Canadian pulp paper cone, high grade Y35 flaw-free ferrite magnet and a robust 5mm square spring terminal connecting block.
Features
- Ultra-high excursion, Low distortion design
- Split winding voice coil
- DCS (Deflective cooling system)
- Water resistant Kevlar loaded paper cone
- Optimized parameters for compact cabinet designs
Specifications
- Nominal diameter: 460mm (18″)
- Nominal impedance: 8 ohms
- Power handling: 1500W RMS (AES Standard)
- Sensitivity: 97dB / 1W / 1m
- Voice coil diameter: 4″ (100mm)
- Voice coil height Hvc: 34mm
- Voice coil air gap Hag: 15mm
- Xmax (Hvc-Hag)/2 + Hag/4: +/- 13.25mm
- Xmech (peak-peak): 62mm
- Voice coil winding: 2 layer IN/OUT
- Voice coil material: IEC grade copper
- Voice coil former: T600 fiberglass
- Suspension: Triple roll, impregnated fabric
- Spider: Dual with silicon damping, NOMEX
- Cone: Fiber loaded treated paper
- Chassis: Die-cast aluminum
- Magnet: 230mm diameter Y35 ferrite
Mounting & Shipping
- Overall Diameter: 470mm
- Bolt circle diameter: 445mm
- Baffle cutout diameter: 422mm
- Flange & gasket thickness: 13mm
- Overall depth: 225mm
- Net weight: 16Kg
- Shipping weight: 19Kg
- Shipping dimensions: 460x460x280mm
T&S Parameters
- F(s): 34Hz
- Q(ms): 9.763
- V(as): 182 liters
- M(ms): 248 grams
- R(ms): 5.553 Kg/s
- S(d): 1225 sq.c+C5m
- V(d): 1.716 liters
- R(e): 5.75 ohms
- Q(es): 0.406
- C(ms): 0.0853 mm/N
- Q(ts): 0.39
- L(e): 1KHz: 1.98mH
- BL: 27.5
- n(0): 1.8%
Celto Acoustique 18SW1000 loose driver
R3,372.00The SW series of subwoofers are the flagship of the CELTO range of loose bass transducers. There has been absolutely no compromise in design, selection of the materials used, manufacturing and the QC process.
The 18SW1000 is a beautifully finished ultra-thick powder coated aluminum die-cast woofer, with a solid <0.1% carbon CNC machined steel T-Yoke, French bobbin with Japanese wire 240°C voice coil, Japanese / USA damper, water resistant fiber loaded Canadian pulp paper cone, high grade Y35 flaw-free ferrite magnet and a robust 5mm square spring terminal connecting block.
Features
- High excursion, Low distortion design
- Deep, clean and puchy bass
- DCS (Deflective cooling system)
- Water resistant Kevlar loaded paper cone
- Optimized parameters for compact cabinet designs
Specifications
- Nominal diameter: 460mm (18″)
- Nominal impedance: 8 ohms
- Power handling: 1000W RMS (AES Standard)
- Sensitivity: 98dB / 1W / 1m
- Voice coil diameter: 3.6″ (91mm)
- Voice coil height Hvc: 25mm
- Voice coil air gap Hag: 10mm
- Xmax (Hvc-Hag)/2 + Hag/4: +/- 10mm
- Xmech (peak-peak): 46mm
- Voice coil winding: 2 layer IN/OUT
- Voice coil material: IEC grade copper
- Voice coil former: T600 fiberglass
- Suspension: Triple roll, impregnated fabric
- Spider: Dual with silicon damping, NOMEX
- Cone: Fiber loaded treated paper
- Chassis: Die-cast aluminum
- Magnet: 220mm diameter Y35 ferrite
Mounting & Shipping
- Overall Diameter: 470mm
- Bolt circle diameter: 445mm
- Baffle cutout diameter: 422mm
- Flange & gasket thickness: 13mm
- Overall depth: 210mm
- Net weight: 9.7Kg
- Shipping weight: 12Kg
- Shipping dimensions: 460x460x280mm
T&S Parameters
- F(s): 35Hz
- Q(ms): 6.224
- V(as): 250liters
- M(ms): 195grams
- R(ms): 6.92 Kg/s
- S(d): 1288 sq.c+C5m
- V(d): 1.28 liters
- R(e): 5.57 ohms
- Q(es): 0.497
- C(ms): 0.101 mm/N
Q(ts): 0.46 - L(e): 1KHz: 1.73mH
- BL: 22
- n(0): 2.08%
Celto Acoustique 18SW1200 loose driver
R4,122.00The SW series of subwoofers are the flagship of the CELTO range of loose bass transducers. There has been absolutely no compromise in design, selection of the materials used, manufacturing and the QC process.
The 18SW1200 is a beautifully finished ultra-thick powder coated aluminum die-cast woofer, with a solid <0.1% carbon CNC machined steel T-Yoke, French bobbin with Japanese wire 240°C voice coil, Japanese / USA damper, water resistant fiber loaded Canadian pulp paper cone, high grade Y35 flaw-free ferrite magnet and a robust 5mm square spring terminal connecting block.
Features
- High excursion, Low distortion design
- Deep, clean and puchy bass
- DCS (Deflective cooling system)
- Water resistant Kevlar loaded paper cone
- Optimized parameters for compact cabinet designs
Specifications
- Nominal diameter: 460mm (18″)
- Nominal impedance: 8 ohms
- Power handling: 1200W RMS (AES Standard)
- Sensitivity: 97dB / 1W / 1m
- Voice coil diameter: 4″ (100mm)
- Voice coil height Hvc: 26mm
- Voice coil air gap Hag: 12mm
- Xmax (Hvc-Hag)/2 + Hag/4: +/- 10mm
- Xmech (peak-peak): 50mm
- Voice coil winding: 2 layer IN/OUT
- Voice coil material: IEC grade copper
- Voice coil former: T600 fiberglass
- Suspension: Triple roll, impregnated fabric
- Spider: Dual with silicon damping, NOMEX
- Cone: Fiber loaded treated paper
- Chassis: Die-cast aluminum
- Magnet: 220mm diameter Y35 ferrite
Mounting & Shipping
- Overall Diameter: 470mm
- Bolt circle diameter: 445mm
- Baffle cutout diameter: 422mm
- Flange & gasket thickness: 13mm
- Overall depth: 212mm
- Net weight: 13Kg
- Shipping weight: 15Kg
- Shipping dimensions: 460x460x280mm
- T&S Parameters
- F(s): 35Hz
- Q(ms): 10.351
- V(as): 205 liters
- M(ms): 215 grams
- R(ms): 4.568 Kg/s
- S(d): 1225 sq.c+C5m
- V(d): 1.225 liters
- R(e): 5.7 ohms
- Q(es): 0.427
- C(ms): 0.0962 mm/N
Q(ts): 0.412 - L(e): 1KHz: 1.98mH
- BL: 25.1
- n(0): 2.03%
BEYMA 18LEX1600Fe
R5,232.00Loose speaker
● High power handling and low distortion 18” subwoofer
● Exclusive Malt Cross® Technology Cooling System
● Low power compression losses
● High sensitivity: 98 dB (1W / 1m)
● FEA optimized ceramic magnetic circuit
● Ultra low air noise
● Optimized linear behaviour
● Weatherproof cone with treatment for both sides
● 3,5” DUO in/out copper voice coil
● Extended controlled displacement: Xmax ± 11 mm
● 51 mm peak-to-peak excursion before damage
● Optimized for direct radiation and band-pass subwoofer
applications
Celto Acoustique 18EX1100-8
R3,014.00Speaker – Replacement driver for CELTO ACOUSTIC 18EX1100-8
Wharfedale wp Impact 18b woofer
R1,824.00Speaker – loose driver 18″
Wharfedale IMPACT18″ 500 Watt 8 Ohm Replacement Woofer Speaker IMPACT18
Wharfedale EVP X18 woofer
R2,434.00Speaker – loose driver 18″
600 Watt 4 Ohm Replacement Woofer Speaker EVP-X18
Celto Acoustique 18EX1400-8
R5,410.0018″ sub loose speaker
1400W RMS
8 ohms
4″ Voice coil
Aluminium basket
Celto Acoustique 18EX900-8
R2,840.0018″ sub loose speaker
900W RMS
8 ohms
3.6″ Voice coil
Aluminium basket
Beyma 18P1000FE V2
R7,433.00Speaker – Loose 18″1000W
18P1000Fe V2 8Ohm Nominal Impedance
8 Ohm
Power Capacity
1000 W Aes
Nominal Diameter
460 Mm 18 In
Sensitivity
98 Db 1 W @ 1 M
Minimum Impedance
6.2 Ohm
Frequency Range
25-2000 Hz
Program Power
2000 W
Recommended Enclosure Volume
80 / 200 L 2.8 / 7 Ft³
Voice Coil Diameter
100 Mm 4 In
Bl Factor
26 N / A
Moving Mass
0.215 Kg
Winding Length
21 Mm
Air Gap Height
12 Mm
Xdamage Pp
52 Mm
Hybrid 18H800
R2,639.0018″ loose speaker
Frame: Die-cast Aluminum basket
Power Handling: 800W RMS
Impedance: 8Ohm
Voice Coil: 4″
Magnet: Ferrite, 173Oz
Efficiency: 1.92%
SPL 1W/1m: 95dB
Fs: 29Hz
Service recone-kit available for this model
Replacement woofer for models;
Hybrid LB18
HYBRID is a South African brand with over 30 years’ experience in professional audio, stage and lighting. Our brand is aimed specifically at the African market to meet our continent’s demands for features, performance and budget.
HYBRID+ is our flagship brand, offering features and performance comparable to world renowned brands and making HYBRID+ one of the best price-to-performance ratio brands.
Hybrid 18H400
R1,892.0018″ loose speaker
Frame: Pressed metal basket
Power Handling: 400W RMS
Impedance: 8Ohm
Voice Coil: 4″
Magnet: Ferrite, 120Oz
Efficiency: 2.4%
SPL 1W/1m: 96dB
Fs: 34Hz
Service recone-kit available for this model
Replacement woofer for models;
Hybrid LB218
HYBRID is a South African brand with over 30 years’ experience in professional audio, stage and lighting. Our brand is aimed specifically at the African market to meet our continent’s demands for features, performance and budget.
HYBRID+ is our flagship brand, offering features and performance comparable to world renowned brands and making HYBRID+ one of the best price-to-performance ratio brands.
Beyma 18PW1400FE
R7,253.00Loose speaker – 18″
8Ohm
1400W AES
98dB 1W/1m
4″ Voice coil
25Hz-1800Hz
Beyma 18LEX1600ND
R8,147.00Loose speaker – 18″
8Ohm
1600W AES
96dB 1W/1m
4″ Voice coil
35Hz-1000Hz
Neodymium
